If heavy foundation costs and weeks of project delays during relocation are eating up your profits, a portable concrete batch plant is the exact flexible concrete production solution you need.
The AIMIX portable concrete plant is engineered to eliminate these traditional construction bottlenecks. Featuring a trailer-mounted chassis and zero-foundation design, it turns weeks of tedious relocation into days，ensuring your projects keep moving with minimal downtime and maximum ROI.
In the construction business，”portable” shouldn’t just mean it has wheels—it must fit your specific site logistics. To save you from expensive logistical bottlenecks, AIMIX Group has designed three series of portable concrete batching plants for sale: the AJY series, AJSY series, and AJZY series. Find your exact match below to compress your transition downtime and protect your bottom line.
Mobility: Loader/Tractor Towed | Project Scale: Small to Medium Rapid-Shift Projects
This is our most efficient fast-transition portable concrete batch plant for sale. Most of the batching, conveying, and mixing systems are highly concentrated on a single compact chassis. It comes equipped with integrated tires and can be towed away effortlessly using a common site wheel loader or a standard trailer truck.
Because it features an ultra-compact footprint and an optimized modular structure, you can complete the dismantling and prepare it for transport in just half a day (0.5 day).
Choose the AJSY series with capacities of 20 and 40 cubic meters per hour, when your projects with a tight schedule that require frequent relocation between multiple nearby sites, or urban construction zones where space is at a premium and you cannot afford days of relocation downtime.
Mobility: Built-in Trailer Chassis | Project Scale: Medium to Large Continuous Projects
The main body—including the twin-shaft mixer, batching machine, and weighing system—is integrated onto a single trailer chassis. You can fold it and hitch it directly to a standard truck tractor.
While the main chassis moves instantly, please note that the vertical cement silos and oversized components require complete disassembly, crane lifting, and separate truck transport. Total relocation, re-erection, and calibration typically take about 3-4 days.
With capacity from 25-100 cubic meters per hour, it is suitable for medium size infrastructure like highways, runways, or bridges where you need high-output commercial concrete and plan to stay at one section for at least 6-12 months before the next big move.
Mobility: Light Trailer Towing | Project Scale: Small / Micro Remote Projects
The AJZY series is engineered for ultimate lightweight mobility. It replaces the heavy twin-shaft mixer with a robust drum mixer. The entire concrete portable batch plant is also equipped with tires, has an incredibly small footprint, and can be easily towed away by a light trailer or truck.
Thanks to the simplified mechanical structure of the drum mixer, it eliminates heavy lifting and complex electrical recalibrations during transit. It features the easiest logistics barrier and a very short setup window, around 1-2 days.
If your projects are located in remote or hard-to-reach areas with tight budgets, and you don’t require high-grade commercial concrete specifications, like rural road paving, mountain paths, island construction. the AJZY drum type mobile concrete plant with capacities of 40 and 60 cubic meters per hour will get the job done where others can’t even arrive.
| Series | Mixing Type | Mobility & Towing | Disassembly Time | Footprint & Setup | Best For |
|---|---|---|---|---|---|
| AJY Series | Twin Shaft Mixer | Truck Tractor (Main Chassis) | 3-5 Days | Medium Footprint | Long-term Infrastructure |
| AJSY Series | Twin-Shaft Mixer | Loader or Trailer | 0.5-1 Day | Ultra-Compact | Frequent Near-Site Shifts |
| AJZY Series | Drum Mixer | Light Trailer / Truck | 1-2 Day | Minimal Footprint | Rural & Remote Terrains |
If you need deep technical configuration details about the portable concrete batching plants, review the detailed engineering parameters below.
| Parameter | AJSY20 | AJSY40 |
|---|---|---|
| Theoretical productivity (m³/h) | 20 | 40 |
| Mixer discharge volume (L) | 500 | 1000 |
| Mixer feeding volume (L) | 750 | 1500 |
| Mixer power (kw) | 18.5 | 18.5×2 |
| Discharge height (m) | 4.1 | 4.1 |
| Aggregate bin configuration (number × single bin volume, m³) | 2×4.5 | 2×4.5 |
| Cycle time (s) | 60 | 60 |
| Maximum aggregate particle size (mm) | 60/80 | 60/80 |
| Cement silo (optional) | 1×100 | 1×100 |
| Weighing Accuracy | Aggregate: ±2%; Powder, Water, Additive: ±1% | |
| Installed power (kw) | ≈50 | ≈70 |
| Control mode | Buttons + Touch Screen + Remote Control | |
| Power supply | 220V/415V/440V/380V, 50Hz/60Hz, three-phase | |
| Model | AJY25 | AJY35 | AJY50 | AJY75 | AJY100 |
|---|---|---|---|---|---|
| Theoretical Productivity (m³/h) | 25 | 35 | 50 | 75 | 100 |
| Mixer Model (Mixer Output L) | JS500 | JS750 | JS1000 | JS1500 | JS2000 |
| Mixer Power (kW) | 18.5 | 30 | 2x18.5 | 2x30 | 2x37 |
| Mixing Cycle Period (s) | 72 | 72 | 72 | 72 | 72 |
| Max.Aggregate Size (mm) | Φ60 | Φ60 | Φ60 | Φ60 | Φ60 |
| Aggregate Bin Capacity (m³) | 4x4m³ | 4x4m³ | 4x5m³ | 4x6m³ | 4x8m³ |
| Powder Storage Silo (ton) | 1x50 | 1x100 | 1x100 | 2x100 | 3x100 |
| Max. Discharging Height (m) | 3.8 | 3.8 | 4.2 | 4.2 | 4.2 |
| Weighing Range & Accuracy of Aggregate (kg) | 2x900kg±2% | 2x900kg±2% | 2x1200kg±2% | 2x1800kg±2% | 2x2400kg±2% |
| Weighing Range & Accuracy of Cement (kg) | 350kg±1% | 500kg±1% | 600kg±1% | 1000kg±1% | 1200kg±1% |
| Weighing Range & Accuracy of Water (kg) | 200kg±1% | 200kg±1% | 350kg±1% | 450kg±1% | 550kg±1% |
| Weighing Range & Accuracy of Additive (kg) | 30kg±1% | 30kg±1% | 30kg±1% | 30kg±1% | 50kg±1% |
| Overall Weight (ton) | ≈15 | ≈20 | ≈25 | ≈31 | ≈37 |
| Installation Power (kW) | ≈65 | ≈75 | ≈90 | ≈125 | ≈180 |
| Parameter | Unit | AJZY-40 | AJZY-60 |
|---|---|---|---|
| Theoretical production efficiency | Cubic meters per hour | 30-40 | 50-60 |
| Drum mixer | Kilowatts | JZM1000 | JZM1500 |
| Motor power | kW | 7.5×2 | 11×2 |
| Mixing time | second | 40 | 40 |
| Discharge height | meters | 1.3 | 1.3 |
| Dosing machine | - | PLD1200 | PLD1600 |
| Hopper capacity | Cubic meters | 5×2/3 | 8×2/3 |
| Motor power | kilowatt | 4×2 | 4×3 |
| Sensor | kilogram | 2000×3 | 2000×3 |
| (Equipment) Size | millimeter | 8410×2000×780 | 11100×2000×780 |
| Tire size | millimeter | 1000 | 1000 |
| Control system | - | PLY1000 Semi-automatic control system | PLY1000 Semi-automatic control system |
Selecting the right portable concrete batching plant for sale ensures optimal site efficiency and long-term cost savings. Instead of getting lost in blueprints, evaluate these four decisive factors to pinpoint your ideal match.
Your project scale dictates your hardware. Avoid buying an oversized asset that drains fuel, or an undersized unit that delays pouring deadlines:
The core mixer governs your concrete quality. Choose based on your project’s rigid structural specifications:
Never look at the concrete plant price tag alone. True ROI comes from minimizing post-purchase daily bleeding expenses:
A stationary or portable batch plant for sale is an investment that requires ongoing lifecycle support. Protect your asset from sitting idle on site:
By carefully considering these factors, you can invest in a solution that enhances productivity, ensures concrete quality, and optimizes operational costs. Whether for which kind of projects, the right concrete portable batch plant type will provide the flexibility and performance needed for successful concrete production.
In the construction industry, the portable concrete batch plant for sale is the perfect solution for civilian construction and precast concrete element production. Whether you’re building residential homes, rural infrastructure, or manufacturing precast slabs and beams, these small portable concrete batch plants for sale deliver efficiency, flexibility, and cost savings. See how our customers have successfully applied them in their projects:
Looking for a reliable portable concrete plant for sale? AIMIX has helped numerous customers improve efficiency and reduce costs in these construction fields. Our portable concrete plants for sale offer the mobility, reliability, and performance you need. You can contact us now to find the perfect solution tailored to your project requirements!
How fast can you move your concrete source when project lines shift? For the AIMIX AJSY series, relocation is no longer a logistical nightmare. Thanks to its highly integrated, all-in-one chassis and foundationless design, your crew can pack up, transport, and resume mixing in record time. Here is the real-world timeline of how the AJSY series portable concrete plant for sale turns weeks of traditional relocation into mere hours.
No complex engineering required. Due to the highly concentrated modular layout, your crew can fold the conveyor, safely pack the main weighing sensors, and complete the entire portable ready mix plant disassembly in just 4 hours.
Skip the wait for specialized oversized transport trucks. Simply hitch the AJSY small concrete plant‘s integrated heavy-duty tires to your site’s existing wheel loader or a standard trailer and pull it out immediately.
Arrive at Site B. Bypass the expensive, time-consuming concrete foundation pouring entirely. Position the plant on any flat, well-compacted ground, unfold the heavy steel base frame, and lock the legs.
Connect to local water, electricity, and raw aggregates. Run a quick, automated test of the water and additive scales using the smart PLC panel to secure mixing precision.
Zero wasted days. By the afternoon of Day 2, the twin-shaft mixer is humming, pouring high-spec commercial concrete right at your new project front—minimizing your site downtime completely.
“Bring the plant to your project, not the concrete.” Investing in an AIMIX portable batch plants for sale eliminates two of the heaviest expenses in traditional construction:
The entire portable concrete plant features an ultra-compact, integrated architecture. By concentrating the feeding, weighing, and mixing processes onto a single trailer unit, it vastly reduces your site footprint and eliminates the high crane rental costs usually required for heavy machinery transit.
Whether utilizing our twin-shaft or drum mixers, you get continuous high-speed output tailored for fast-paced projects. Equipped with specially treated wear-resistant liner plates and mixing blades, alongside unique shaft-end seals, the mixer’s service life is extended by 35%, preventing unexpected downtime during crucial pours.
Maximize your project momentum. Our modular engineering allows for rapid deployment, getting the system fully operational in less than a week. When the job wraps up, a quick 0.5 to 1-day disassembly allows you to pack up and transition to your next profit-generating site without leaving expensive assets behind.
Take full control with an intuitive PLC computer control system supporting both automatic and manual modes. The dynamic real-time panel display provides instant tracking of every aggregate component. Plus, on-demand report storage and printing offer seamless production scheduling and transparent material cost management.
To ensure high precision and uncompromised reliability, core components—including the reducer, metering sensors, and critical electrical switches—utilize premium imported brands. This high-standard hardware cuts electrical failure rates by 40% while securing strict weighing accuracy to meet rigid commercial concrete standards.
How does a heavy-duty, high-output batching plant portable fold onto wheels? AIMIX engineers have mastered the art of modular integration. Taking AJY Series for example, you can explore its main structure:
The AJSY model offers a significant advantage in international shipping. This helps lower freight costs and improve logistics efficiency.
Power requirements depend directly on your selected capacity. For example, our AJY-35/AJSY-40 requires a total installed power of approximately 60 kW to 65 kW. If your site lacks grid electricity, we recommend equipping a 100 kVA to 120 kVA diesel generator set to ensure flawless, continuous mixing operations.
Our advanced PLC automation keeps labor costs incredibly low. You only need 3 to 4 people to run standard daily operations: 1 control room operator, 1 wheel loader driver (for feeding aggregate), and 1-2 site helpers. For relocation, a standard crew of 4 workers can complete the entire teardown or setup process smoothly.
Absolutely. Both our AJY and AJSY series utilize industrial-grade JS twin-shaft concrete mixers. Combined with high-precision independent weighing sensors, our systems mix concrete with extreme homogeneity, easily meeting the strict engineering standards required for highway pavements, commercial high-rises, and precast factories.
Yes, the AJSY and AJZY series can achieve zero-foundation installation. Thanks to their integrated heavy-duty steel base frame, the compact small concrete plant can be placed directly on flat and well-compacted ground and start production quickly.
For the AJY series, some foundation work is still required, especially for the cement silo, to ensure stable and safe operation.
When selecting a portable concrete batching plant manufacturer in China, AIMIX stands out as a reliable choice. With over 500 sets of portable batching plants successfully exported to more than 100 countries, we deliver the industry-proven engineering your contracts demand.
Every portable batch plant we manufacture holds strict CE and ISO certifications. This guarantees your equipment complies with international safety, environmental, and engineering standards, facilitating smooth local site approvals.
To eliminate communication gaps and long shipping delays, we maintain fully staffed local branch offices in some countries, like Indonesia, Malaysia, Russia, Saudi Arabia, Nigeria, etc. This puts real engineering support right in your time zone.
Our specialized global services department coordinates your entire operational lifecycle. From initial site checking and foundationless calibration to custom operator training and rapid hardware troubleshooting, we ensure your plant maintains peak uptime.
By eliminating middleman markups, we pass maximum capital savings directly to you. Our optimized manufacturing supply chain ensures premium, high-spec machinery at a highly profitable return on investment compared to Western alternatives.
Ready to maximize your concrete production and slash site logistics costs? Let’s discuss your project parameters! Contact AIMIX today via our quick inquiry form, email, phone, or WhatsApp, and our engineering sales team will deliver a customized quote promptly.
